Versatile Piezo High Resolution Inkjet Printer Eco Friendly UV Inkjet Printer
  • Versatile Piezo High Resolution Inkjet Printer Eco Friendly UV Inkjet Printer
  • Versatile Piezo High Resolution Inkjet Printer Eco Friendly UV Inkjet Printer
  • Versatile Piezo High Resolution Inkjet Printer Eco Friendly UV Inkjet Printer

Versatile Piezo High Resolution Inkjet Printer Eco Friendly UV Inkjet Printer

Place of Origin China
Brand Name Syscode
Certification CE
Model Number S7180
Product Details
Product Name:
High Definition UV Inkjet Printer Syscode S7180
Physical Resolution:
600DPI
Printing Height:
53.95mm
Ink Dot Size:
3.5PL/6PL
Ink Dot Type:
1 To 7 Dots
Printing Distance:
1 To 25mm
Complete Machine Size:
Length 45cm Width 36cm Height 85cm
Nozzle Self-repair:
Support
Relative Humidity:
<80RH,no Frost
Highlight:

Versatile Piezo High Resolution Inkjet Printer

,

Versatile UV Inkjet Printer

,

Eco Friendly UV Inkjet Printer

Payment & Shipping Terms
Minimum Order Quantity
1Set
Price
Negotiation
Packaging Details
Carton Packing
Delivery Time
3-5 work days
Payment Terms
T/T
Product Description

High Definition UV Inkjet Printer

Make a more stable UV inkjet printer

PIEZO INKJET PRINTER ADVANTAGES
High resolution printing

• Compared with traditional marking equipment,thephysical resolution of piezo inkjet printers can reach upto 600DPl,and other resolutions such as 180,300,and360 are available.

Excellent nozzle durability

• Whether it is oil-based ink for permeable surfacematerials or UV-curable ink for non-permeable surfacematerials,because it does not contain solvents, undernormal maintenance,even if it is stopped for a longtime.the nozzleis not easv to be blocked.

Large format printing

• The printing format of a single printhead is32.4mm,54mm,71.8mm,etc.,and the printingspeed is not affected by the adjustment of thenumber of content ines and height, and a largerprinting format can be obtained through the multi-head seamless splicing technology.

Environmentally friendly

• Both oil-based inks and UV-curable inks used in piezoinkjet printers have no VOC emissions

Versatile Piezo High Resolution Inkjet Printer Eco Friendly UV Inkjet Printer 0

SAMPLE DISPLAY:

Versatile Piezo High Resolution Inkjet Printer Eco Friendly UV Inkjet Printer 1

Advantages of printheads-internal circulation technology

◆ Patented internal circulation technology

The high-flow internal circulation technology that flows directly   through all nozzle channels has a great inherent advantage over other printhead ink chamber circulations.

◆Application value

·Stability:The internal circulation directly takes away the bubbles and impurities in the printing chamber to ensure the stability of    continuous printing

·Moisture retention:greatly extends the standby time,start the machine and spray immediately,reduce the maintenance and  cleaning frequency

·Printhead life is greatly extended:The internal circulation

self-repair function greatly reduces the printhead oblique spraying and plugging holes,extending the printhead life

·White ink adaptability:The internal circulation prevents the precipitation of large-particle pigment ink,and extends the standby time from 20 to

30 minutes of ordinary models to half a month or even longer

Advantages of printheads-highinkdroplet speed+high drop pointaccuracy



◆Ink droplet flight speed

·The ink droplet speedy of the jet reaches over 10m/s

·Reduce the difference in thelanding point of different dot types, especially the landing point accuracy of small ink dropets

·High jet force is suitable for high drop and high gap printing



◆Jet angle error

Jet angle:within 1.3mrad,which is equivalent to the ejected ink droplets can fall on the 10cm bull's eye 50 meters away. The smalljet error greatly guarantees the landing point

accuracy of 3~4pl ink droplets



◆Application value

·Higher printing distance can reach 25mm

Expanded from 1 to 3mm of ordinary printheads to

1 to 25mm to avoid scratching the printhead

·Single head larger printing width

S3300:Single head can print 53.95mm height content

S5600:Single head can print 108mm height content

Nozzle advantage-ultra-high resolution finishing technology

·More accurate landing point,can print smaller fonts

◆Single column 300dpi Nozzle processing technology

The S3300 model has a single row of 300dpi nozzles for industrial printheads,while the 600dpi printhead is   composed of only two rows of nozzles



 ◆Application    value

·Further improve the printing quality,reduce or avoid the appearance of streaks,ghosting,orjagged edges in the print

·Can be used in production lines or scenes where objects are shaking and unstable



Performance parameters



Model

S7180/S7360

S5300

S3300

S5600

System

Syscode variable data high-speed printing system(Android/Windows optional)

Screen

13.3-inch touch screen/15.6-inch touch screen

Printhead type

Seiko 510/Seiko 1020

Toshiba   CE4

Ricoh G4

Ricoh   G5

Printing height

Single head:71.8mm

Single head:53.7mm

Single head:32.4mm

Single head:54mm

Physical resolution

180DPI/360DPI

300DPI

600DPI

Printing direction resolution

100DPI to 3000DP

300,600,900,1200DPI

100DPl to 3000DPI

Ink dot size

35PL/50PL,12PL/35PL

5PL

7PL

Ink dot type

1 dot

1 to 7 dots

1 to 3 dots

Speed

Up to 100 m/min

Up to 66 m/min

Up to 165 m/min

Up to 330 m/min

Printing directon

Upward spray,downward spay,side spray

Downward spray,side spray

Upward spray,downward spray,sde spray

Ink supply system

Negative pressure

Temperature/humidity

0℃-45℃<80RH,no frost

FAQ

High-resolution UV inkjet printer with 13.3-inch / 15.6-inch touchscreen, industrial-grade Android and Windows operating systems, offering rich features and enhanced stability. Supports hundreds of fonts, various 1D and 2D barcodes, and allows importing JPG, BMP, PNG, PDF documents, and Excel variable data for printing, providing powerful functionality.

Easy touch control, dual-head design, capable of meeting various coding requirements.
We promise to deliver only the most stable UV inkjet printers!

Q1. Can I apply for a sample order?

A: Yes, we welcome sample orders for testing and quality inspection. Mixing different models is also possible.

Q2. What is the delivery time?

A: Sample preparation takes 3-5 days, while large-scale production requires 8-10 working days.

Q3. Is there a minimum order quantity for high-resolution UV inkjet printers?

A: There is a low minimum order quantity; we can provide 1 unit for inspection.

Q4. How do you ship, and how long will it take?

A: We ship via DHL, UPS, FedEx, or TNT, which usually takes 3-5 days. Air and sea freight options are also available.

Q5. How do I place an order for a high-resolution UV inkjet printer?

A: First, let us know your requirements or application.
Second, we will quote based on your needs or our recommendations.
Third, the customer confirms the sample and pays a deposit to officially place the order.
Fourth, we arrange production.

Q6. Can I print my logo on the high-resolution inkjet products?

A: Yes, please inform us formally before production.

Q7. Do you provide a product warranty?

A: Yes, we offer a 1-year warranty for our products.

Q8. How do you handle defective products?

A: First, our products are manufactured under a strict quality control system, with a defect rate of less than 0.1%.
Second, during the warranty period, we will replace small batches of defective high-resolution inkjet printers with new units. For large batches of defective products, we will repair and return them, or discuss solutions based on the situation, including recalls.
